Theodolite Surveying Instrument

Theodolite Surveying Instrument
Theodolite Surveying Instrument
Product Code : TSI 20
Brand Name : SUPERTECH SALES & SERVICES PVT. LTD.
  • Minimum Order Quantity
Trade Information
  • Payment Terms
  • Cheque, Others
  • Main Domestic Market
  • Uttar Pradesh
Product Description

Supported with the excellence of a highly professional team, we are recognized as one of the topmost suppliers of a wide range of Theodolite Surveying Instrument. This instrument is extensively used for measuring both horizontal and vertical angles. Suitable for triangulation networks and geo-location work, this is high in demand in land surveying and engineering industry. Theodolite Surveying Instrument is offered to clients in different specifications to meet their particular requirements.

Features:

  • Easy installation
  • Rugged design
  • Light in weight

Technical Specification:




Telescope
Image Erect
Magnification 30X
Effective Aperture 45 mm
Resolution 3”
Field of View 1030’
Minimum Focusing Distance 1.4 m
Stadia Ratio 100
Stadia Constant 0
Tube Length 157 mm
Angle Measurement
Measurement Method Incremental Photo Electronic Encoding
Raster Disk Diameter (VHz) 79 mm
Minimum Reading 1/5” (optional)
Accuracy 2"
Hz Angle: Dual
V. Angle : Dual
5”
Hz Angle: Dual
V. Angle : Single
Display
Display Type 2 Sides, Large LCD
Data Output
Data I/O RS 232
Sensitivity Of Vial
Plate Vial 30”/2 mm
Circular Vial 8’/2 mm
Auto Vertical Compensator
System Liquid-Electric Detection
Working Range ±3’
Accuracy 1” (Liquid-Electric Detection)
